The Hougen HMD904 115V magnetic drill is a serious fabrication tool, and the most important question before buying it is not whether a mag drill can make holes in steel. It is whether the exact HMD904 variation, cutter system, power requirement, capacity and base configuration match the work you actually do. Amazon ASIN B003M5IT9Y is tied to the 115-volt HMD904 family, but Hougen sells several 115V HMD904 configurations. That variation check belongs at the top of the buying decision.
Hougen HMD904 115V: start with the machine’s real capacity
Hougen lists the HMD904 with a 7/16-inch to 1-1/2-inch diameter capacity and up to 2 inches of cutting depth when using the specified annular-cutter system. The manufacturer identifies 12,000-Series and Copperhead carbide cutters with a 3/4-inch shank. Those are machine specifications, not a promise that every cutter, material or drilling condition will perform the same way.
The 115V electrical system is listed at 50/60 Hz, 9 amps and 1035 watts, with a 450 RPM motor. Verify the branch circuit, extension-cord requirements, generator capacity if applicable, and jobsite power against Hougen’s instructions before use. “Runs on 115V” is useful, but it should not be reduced to “plug it into any outlet.”
The HMD904 name covers more than one 115V configuration
Hougen’s current product page lists multiple 115V versions. Part 0904101 is a standard HMD904. Part 0904102 adds the coolant-bottle configuration. Part 0904103 adds a swivel base. Part 0904104 combines coolant bottle and swivel. Hougen also lists Fabricator’s Kit versions and a permanent-magnet version. That is why a listing that only says “HMD904 115V” is not enough to assume swivel, coolant-bottle or cutter-kit contents.
Hougen says all drills in the listed family include a carrying case, a pint of coolant, a safety chain and hex wrenches, while the Fabricator’s Kit adds a 1/2-inch drill chuck, adapter and a 12,000-Series cutter kit. Still compare the exact Amazon model/part description with Hougen’s configuration table before ordering, because package presentation can change and Amazon sellers may describe variants differently.
Swivel base or standard base?
The swivel-base versions are aimed at alignment flexibility after the magnetic base is positioned. Hougen describes a 1-inch-wide by 3/4-inch-long swivel adjustment area and promotes the design for lining the pilot up with the intended hole center. If your work regularly involves crowded assemblies, horizontal drilling, or repeated alignment corrections, that feature may justify choosing the correct swivel model rather than a standard-base unit.
If most of your drilling is on open plate where the machine can be positioned easily before the magnet is energized, the standard configuration may be sufficient. The important point is to buy the feature intentionally rather than discover after delivery that the Amazon listing was a different HMD904 variation.
Magnetic holding force depends on the workpiece
Hougen publishes magnet holding data at both 1-inch and 3/8-inch plate thicknesses, and the numbers are different. That is a useful warning against treating one maximum holding-force figure as universal. Surface condition, thickness, material, geometry and full base contact matter. Follow Hougen’s operating instructions and use the supplied safety chain as required; do not rely on a headline magnet number as a substitute for setup checks.
A magnetic drill is also the wrong tool when the base cannot establish the required magnetic attachment. Nonferrous material, unsuitable stainless grades, thin work, coatings, scale, gaps or irregular surfaces can change the situation substantially. Verify the material and setup before choosing a mag drill just because the hole size is within the cutter capacity.
Annular cutters change the economics of the purchase
The HMD904 is built around annular-cutting capability. If your shop already stocks compatible 3/4-inch-shank Hougen cutters, the machine may fit an existing consumable system. If it does not, include the cutter sizes, pilots, lubricant and replacement plan in the real cost of putting the drill to work. A machine that fits the hole range but requires an entirely new cutter inventory is a different buying decision from one that drops into a system your shop already owns.
Also distinguish the base HMD904 capacity from the broader Hougen cutter catalog. Hougen sells cutters larger and deeper than the HMD904’s stated 1-1/2-inch by 2-inch machine capacity. Cutter availability in the same brand does not expand this drill’s rated capacity.
Who should look closely at the HMD904?
This machine makes the most sense for fabrication, erection, maintenance and field work where accurate holes must be produced in ferromagnetic steel and bringing the workpiece to a stationary drill press is impractical. Its compact footprint, 115V option and annular-cutter capacity are the reasons it is worth comparing against smaller handheld drilling methods and larger shop-only machines.
It is less compelling when the work is mostly nonmagnetic material, when the base cannot seat safely, when hole sizes routinely exceed the HMD904 capacity, or when the job requires a feature found only on another HMD904 configuration. Those are not defects in the machine; they are reasons to match the tool to the work before spending money.
Amazon product check
As an Amazon Associate I earn from qualifying purchases.
- Large 1-1/2″ x 2″ capacity, The Drill of Choice for Fabrication
- Lightweight, Powerful and Versatile, Hidden motor cord , Ergonomic housing
- Increased Safety with Less Maintenance, Lower Overall Height, Lift Detector Safety System
- LED Pilot Light for Low Light Conditions and Greater Hole Accuracy
- Slot Drive Arbor for More Accuracy and Quicker Change Out of Accessories
Last update on 2026-09-30 / Affiliate links / Images from Amazon Product Advertising API
The box above is for ASIN B003M5IT9Y, identified as a Hougen HMD904 115V magnetic drill. Before ordering, compare the exact Amazon model/variation and included items against Hougen’s current HMD904 configuration table. Do not infer swivel base, coolant-bottle configuration, Fabricator’s Kit or permanent-magnet features unless the exact listing says so.
Why this is a revenue-opportunity article
The HMD904 is a useful affiliate-content candidate because a buyer has several concrete questions to solve before purchase: voltage, hole capacity, cutter system, standard versus swivel base, included equipment and the condition required for a magnetic base. That is stronger commercial intent than a generic “best mag drills” list. No Amazon earnings, demand, conversion rate or commission rate is assumed here because those performance data were not available in this workflow.
Featured image: contextual metal-drilling photo by Blaz Erzetic via Unsplash; it does not depict the Hougen HMD904.
