ER4043 vs ER4047 MIG Wire: Why More Fluidity Is Not the Whole Decision

When comparing ER4043 vs ER4047 MIG wire, do not select only for how readily the puddle flows. Hobart describes its 4047 wire for applications where higher fluidity and lower shrinkage are useful, but also identifies very low ductility, formability and toughness. Those tradeoffs matter when the finished joint must do more than look well wetted.

Both classifications belong to the aluminum filler-metal selection discussion. Neither is a universal answer for unknown castings, pressure-containing parts or every aluminum alloy. Identify the base material and the job requirements first. A different filler is a procedure decision, not a general cure for a difficult weld.

The manufacturer comparison that changes the question

Hobart MaxalMig 4043 is described as a general-purpose aluminum-silicon filler. Its listed characteristics include high fluidity and low shrinkage, alongside low ductility, formability and lower toughness. Hobart identifies the product under AWS A5.10 ER4043 and R4043.

Hobart MaxalMig 4047 is identified under AWS A5.10 ER4047 and R4047. Hobart highlights thin-section applications in which higher fluidity and lower shrinkage matter, and applications seeking wetting for joint sealing. The same description explicitly lists very low ductility, formability and toughness. A listed sealing application is not a guarantee that a particular weld is leak-tight or approved for pressure service.

That is the useful contrast: an attractive handling characteristic must be considered together with the required performance of the completed joint. Do not read the fluidity benefit and overlook the mechanical-property limitations printed beside it.

Fluidity, shrinkage and ductility answer different questions

Fluidity describes the behavior of the molten material. Shrinkage concerns dimensional change as the material solidifies and cools. Ductility concerns deformation of the solid material. These are not three names for the same quality. Improving the feature that helps the welder place metal does not automatically improve the feature needed when the component is loaded.

For example, a purchasing discussion centered on a thin fabricated enclosure may emphasize distortion and the joint’s sealing requirement. A different component may have forming, impact or other mechanical requirements. These are illustrative decision questions, not approvals for either filler. Engineering and the governing procedure must establish which characteristics the actual joint requires.

Classification is not an exact spool

ER4043 and ER4047 are classifications. A manufacturer product adds its own identity, published data and available package choices. A purchase order then needs the correct wire diameter, package format, quantity and any required documentation. Do not stop after the classification if the feeder, purchasing unit or quality system requires more information.

Hobart’s 4047 product listing, for example, identifies part 404703512 as 0.035-inch wire in a 16-pound wire-basket package. That is an example of an exact manufacturer product configuration, not a statement of retailer inventory or universal feeder compatibility. Confirm the receiving equipment and required packaging before using any listed configuration on a purchase order.

Keep MIG wire and TIG rod separate

This comparison uses MaxalMig product documentation and the WSP MIG/GMAW grade pages. Do not turn a MIG-wire package listing into proof that an equivalent TIG-rod diameter or package is stocked. The process and physical form belong on the order even when the classification looks familiar.

That distinction also keeps setup advice honest. A classification does not establish the correct liner, drive-roll configuration, contact tip, shielding arrangement or operating parameters for an unspecified machine. Use the equipment instructions, the exact filler product data and the approved procedure rather than copying settings from another aluminum job.

Typical data are not specification limits

A manufacturer’s typical property is information about that product under the conditions described. It is not automatically the minimum required by AWS, a guaranteed property of every production joint, or a substitute for the customer’s acceptance criteria. When comparing data sheets, check which material condition and test basis are being described before treating two values as directly comparable.

The same caution applies to qualitative descriptions. The words low and very low in the cited Hobart pages help identify a tradeoff. They do not supply a numerical acceptance limit for a particular component. Obtain the current product documentation and job requirements when a property is important enough to control selection.

Before proposing a change from 4043 to 4047

• Identify the exact base-metal alloy and whether the component is cast or wrought.
• Read the drawing, WPS, repair authorization and applicable customer or code requirements.
• State the actual problem: wetting, distortion, feeding, contamination or a failed acceptance requirement. Do not assume the filler causes every problem.
• Review required strength, deformation, toughness, temperature and corrosion-service considerations with the responsible technical authority.
• Compare current manufacturer documents for the exact products and process forms.
• Obtain the required procedure review or qualification before changing the approved consumable.

Unknown base metal or service requirements should remain unresolved questions, not assumptions filled in from the most convenient spool label. This guide intentionally does not prescribe a universal preheat, interpass temperature, voltage, wire-feed speed or heat treatment.

Use the WSP lookup path correctly

Start with the exact ER4043 MIG/GMAW page and ER4047 MIG/GMAW page. Use Alloy Support to organize material questions and the Filler Metal Finder to narrow possible classifications. Finder results do not approve welding procedures.

The existing ER4047 support notes cover general identification and ordering checks. This comparison adds the manufacturer-described fluidity-versus-ductility tradeoff that should inform a substitution discussion.

Bottom line: consider 4047’s handling characteristics together with the completed joint’s required properties. More fluidity is one selection factor, not a reason to bypass material identification, product-form checks or WPS review.
